BrandCOLO powder coating machine
ModelCL-191s
Powder coating equipmentmanual
Voltage:100-240 VAC
powder hopper50L
Power(W)50W
Dimension(L*W*H):56*52*69CM
Weight:55KGS
FOB portFOB NINGBO o SHANGHAI
Terms of PaymentT/T, Western Union, paypal
Download DOC
Update Time2020-07-07
Detail Information
CL-191S Powder Coating Machines
Unprecedented precision control of current and voltage ensuring maximum efficiency and uniformity of coating.

Flat Parts, maximizes voltage for optimum transfer efficiency.
Complex Parts, modifies voltage while holding current for optimum penetration and transfer efficiency.
Recoat Parts, automatically adjusts voltage and current to the optimum level for recoating previously coated parts.

offers mobility and flexibility allowing operators to position the unit for easy access and adjustment.
Electrical Data
Nominal input voltage
110V240VAC
Frequency
50-60Hz
Connected load (without vibrator)
40 VA
Nominal output voltage (to the gun)
eff.10 V
Nominal output current (to the gun)
max. 1.2 A
Connection for rinsing function (valve)
24 VDC max. 3 W
Temperature range
0°C - +40°C(+32°F - +104°F)
Max. surface temperature
85 °C (+185 °F)
Approvals
II 3 D IP54 120 °C
Pneumatical Data
MAX.input pressure
10bar
MIN.input pressure
6bar
Input pressure (Dynamic based on pressure regulator setting)
5.5 bar / 80 psi
Max.water vapor content of the compressed air
1.3g/Nm³
Max.oil vapor content of the compressed air
0.1mg/Nm³
Max.compressed air consumption
11Nm³/h
The related spare parts for COLO powder coating Machines.
